品牌：RETZ瑞茨/我們一直致力于流體控制領域的持續創新，始于2005……進口高頻率電磁閥 是一種快速開關的電磁閥，其通過電磁線圈組件通電后，使電磁線圈組件與靜鐵芯形成電磁鐵而形成電磁力，動鐵芯的電磁力的作用下向上運動從而與閥口處脫離而使電磁閥打開，由于靜鐵芯與動鐵芯之間設置有隔磁片，避免了靜鐵芯與動鐵芯之間的直接接觸，從而保證動鐵芯高頻率運動的靈敏性和準確性另外，動鐵芯的下端嵌置有密封墊，保證了閥口處的密封性；閥口的上表面為一斜面，使動鐵芯的下端與閥口的接觸為線接觸

High frequency electromagnetic valve is a type of fast switching electromagnetic valve. After being energized by the electromagnetic coil component, the electromagnetic coil component forms an electromagnet with the static iron core, forming an electromagnetic force. The electromagnetic force of the moving iron core moves upward and separates from the valve port, causing the electromagnetic valve to open. Due to the setting of a magnetic separator between the static iron core and the moving iron core, direct contact between the static iron core and the moving iron core is avoided, To ensure the sensitivity and accuracy of high-frequency movement of the moving iron core, in addition, a sealing gasket is embedded at the lower end of the moving iron core, ensuring the sealing at the valve port; The upper surface of the valve port is an inclined plane, making the contact between the lower end of the moving iron core and the valve port a line contact

高頻率電磁閥為直動式活塞結構,用于頻繁快速啟閉的場合RETZ The high-frequency electromagnetic valve is a direct acting piston structure, used for frequent and fast opening and closing situations

進口高頻率電磁閥工作原理--

常閉（斷電關閉）

當通電時，電磁力將閥座打開，

當斷電時，彈簧力將閥座關閉

控制類型：電磁直動式

進口高頻率電磁閥規格尺寸--

連接形式：螺紋、法蘭連接

壓力范圍：0-25Bar

尺寸范圍：1/4"-4"

適用介質：中性，腐蝕性液體和氣體

介質粘度：最大50 cst(mm2/s)

介質溫度：-20℃ — +130 ℃

環境溫度：-30℃ — +60 ℃

閥門材質：CF8

密封材質：FPM

控制電源：DC24~127V；AC36~380V

防護等級：IP65

泄露等級：DIN EN 12266 A級
